10. With the locking lever in the 180 degree position the guide plates can be removed from the connector body.

Note:  During assembly the TPA will not fully seat if any terminal is not fully seated.

11. Using terminal release tool J 38125-11A or equivalent, remove the TPA from the connector body.
