Cooling systemRadiator cooling fan - ’k’ series with air conditioning · page 1 of 2

Refit

  1. Manoeuvre cooling fan housing around radiator top hose and into position on radiator studs.
  2. Fit 4 nuts securing cooling fan housing to radiator and tighten to 9 Nm.
  3. Secure radiator top hose to clip on cooling fan housing.
  4. Connect multiplug to radiator cooling fan.
  5. Connect battery earth lead.

RADIATOR COOLING FAN - ’K’ SERIES WITH AIR CONDITIONING

Service repair no - 26.25.22.20

Remove

  1. Disconnect battery earth lead.
  2. Remove air cleaner. See ENGINE MANAGEMENT SYSTEM - MEMS, Repairs.
  3. Position container to catch fluid loss from radiator.
Radiator cooling fan - ’k’ series with air conditioning – Position container to catch fluid loss from radiator.
  1. Disconnect multiplug from radiator cooling fan.
  2. Loosen clip securing radiator top hose to coolant outlet elbow.
  3. Disconnect top hose from radiator.
  4. Release radiator top hose from clip on cooling fan housing and position top hose aside.
  5. Disconnect multiplug from coolant temperature sensor.
