Refit (page 2 of 2)

Make

Rover

Model

Coupé, Cabriolet & Tourer 200/400 Coupé, Cabriolet & Tourer Workshop Manual

Section

Repairs

Engine 1.6Refit · page 2 of 2

40. ABS 6: Attach ABS pipe clip to battery tray; tighten bolt to 9 Nm.
41. Connect trunking to throttle housing and breather pipe and connect to air cleaner, tighten clip.
42. Connect vacuum pipe to air cleaner.
43. Fit air duct and clip expansion tank hose on top.
44. Fit side branch to air duct and engage clip.
45. Connect engine earth lead to bonnet lock platform.
46. Fit battery into tray, fit clamp and tighten bolt; connect both battery leads.
47. Fit underbelly panel, see BODY – Repairs.
48. Remove stand(s) and lower vehicle.
49. Fill gearbox with correct quantity and grade of oil, see INFORMATION – CAPACITIES, FLUIDS AND LUBRICANTS
50. Fill engine with correct quantity and grade of oil, see INFORMATION – CAPACITIES, FLUIDS AND LUBRICANTS
51. Refill cooling system, see MAINTENANCE
52. Fit bonnet, see BODY – Repairs.
53. Check ignition timing, see MAINTENANCE
