Discovery II
TRANSFER BOX - LT230SE
41-48
OVERHAUL
15. Position tool LRT-51-003 to output shaft drive
flange, remove and discard nut, steel and felt
washers; remove output shaft drive flange.
16. Using a copper mallet, drive output shaft from
housing, recover bearing spacer.
17. If fitted: Noting its fitted position, remove dog
clutch from output shaft.
18. Remove and discard oil seal from housing.
19. Remove and discard circlip retaining output
shaft bearing.
20. Support housing and drift out output shaft
bearing.
21. Remove and discard differential bearing track
and collect selective shim.
