Discovery II
TRANSFER BOX - LT230SE
OVERHAUL
41-57
Refit
1. Clean differential components. Remove all
traces of sealant from housings and bolts,
differential lock warning lamp switches and
detent plugs.
2. Lubricate components with gearbox oil.
3. Position differential in soft jawed vice and fit
front bearing using tool LRT-41-008.
4. Invert differential in soft jawed vice, and fit low
range gear with dog teeth facing uppermost.
5. Fit high/low hub ensuring that machined
groove on hub teeth faces towards low range
gear.
6. Fit high/low selector sleeve ensuring that
alignment marks on hub and sleeve are
together.
7. Fit bush to high range gear ensuring collar is
uppermost.
8. Fit high range gear and bush onto shaft.
9. Fit new rear bearing using tool LRT-41-008.
