Range Rover V8 Engine Oil Pressure Switch Repairs
ENGINE - V8
12-2-60 REPAIRS
Baffle Plate
$% 12.60.46
Before disconnecting the battery, ensure all text and
cautions in the battery disconnection section are
observed.
GENERAL INFORMATION, Electrical
Remove
1. Position vehicle on lift.
2. Disconnect battery earth lead.
3. Remove engine oil sump.
Engine - V8, REPAIRS, Gasket - oil
4. Remove 6 bolts securing baffle plate and
remove plate.
Refit
1. Fit baffle plate and tighten bolts to 10 Nm (7
lbf.ft).
2. Fit engine oil sump.
Engine - V8, REPAIRS, Gasket - oil
3. Connect battery earth lead.
Switch - oil pressure
$% 12.60.50
Before disconnecting the battery, ensure all text and
cautions in the battery disconnection section are
observed.
GENERAL INFORMATION, Electrical
Remove
1. Disconnect battery earth lead.
2. Disconnect multiplug from oil pressure switch.
3. Position absorbent cloth beneath oil filter
housing to collect spillage.
4. Remove oil pressure switch from oil filter
housing and discard sealing washer.
M18 0740
