L322 Range Rover Service Procedures
ENGINE - V8
12-2-54 REPAIRS
Filter - engine oil
$% 12.60.04
Before disconnecting the battery, ensure all text and
cautions in the battery disconnection section are
observed.
GENERAL INFORMATION, Electrical
Remove
1. Position absorbent cloth beneath oil filter
housing to collect spillage.
2. Remove oil filter cap and filter element from oil
filter housing. Remove oil filter element from oil
filter cap. Discard filter element and 2 'O' rings.
Refit
1. Clean oil filter cap and housing.
2. Fit 2 new oil filter 'O' rings and lubricate with
clean engine oil.
3. Fit new oil filter element into oil filter cap.
4. Fit oil filter cap and tighten to 25 Nm (18 lbf.ft).
5. Remove absorbent cloth.
6. Clean oil filter cap and housing.
7. Remove engine oil dipstick.
8. Remove engine oil filler cap and fill engine to
correct level.
9. Clean engine oil filler cap and mating face.
10. Fit engine oil filler cap.
11. Fit engine oil dipstick.
12. Start engine and run at idle speed until oil
pressure warning light extinguishes.
13. Visually check oil filter cap for signs of leakage.
14. Stop engine, wait a few minutes, then check oil
level. Top up if necessary.
Tube - dipstick
$% 12.60.09
Before disconnecting the battery, ensure all text and
cautions in the battery disconnection section are
observed.
GENERAL INFORMATION, Electrical
Remove
1. Position vehicle on lift.
2. Disconnect battery earth lead.
3. Remove dipstick.
4. Remove 2 nuts securing dipstick tube bracket
to camshaft cover.
5. Remove nut and clamp securing dipstick tube
to oil sump.
6. Remove dipstick tube, washer and 'O' ring,
discard 'O' ring.
