L322 Range Rover Service Procedures
FRONT SUSPENSION
60-14
REPAIRS
8. Remove and discard circlip.
9. Fit adapter, LRT-60-033/6 to bearing and using
method previously described, remove bearing.
10. Remove pins LRT-60-033/3.
11. Remove bearing track from drive flange using a
bearing separator.
Refit
1. Clean hub and drive flange.
2. Position anvil, LRT-60-033/10 to bed of
hydraulic press and locate hub on anvil.
3. Ensure hub and bearing mating surfaces are
clean and dry.
4. Apply stud/bearing fit, STC 50553 to bearing
mating surface in hub for half its length.
5. Press bearing into hub using adapter LRT-60-
033/12.
M60 0835
