L322 Range Rover Service Procedures
STEERING
57-8
REPAIRS
12. Note fitted position for refit and remove cable
ties securing LH height sensor harness to sub-
frame and sensor.
13. Disconnect height sensor multiplug.
14. Remove 2 bolts securing height sensor and
remove height sensor.
15. Remove Torx screw from steering column
lower clamp.
16. Rotate steering wheel to straight ahead
position, align pinion timing marks and remove
ignition key.
CAUTION: Do not turn the steering wheel
with the intermediate shaft or universal joint
disconnected as damage to the rotary
coupler and the steering wheel switches
may occur.
17. Disconnect column from pinion.
18. Disconnect multiplug from PAS rack pinion
sensor.
19. Release 5 clips securing engine mounting
vacuum hose to PAS rack.
20. Position container to collect PAS fluid spillage.
CAUTION: Before disconnecting or
removing components, ensure the
immediate area around joint faces and
connections are clean. Plug open
connections to prevent contamination.
M54 0186
M57 1137
