Range Rover P38
LAND ROVER V8
41
REPAIR
FUEL FILLER NECK - ADVANCED EVAPS
Service repair no - 19.55.07
Remove
WARNING: Ensure that fuel handling
precautions given in 01 - Introduction are
strictly adhered to when carrying out
following instructions.
WARNING: If the fuel tank is full, the fuel
level may be close to the filler neck
aperture. If gauge indicates over 75%,
drain a minimum of 10 litres (2.6 US Gallons) from
fuel tank.
See Adjustment.
CAUTION: before disconnecting any part
of the system, it is imperative that all dust,
dirt and debris is removed from around
components to prevent ingress of foreign matter
into fuel system.
Remove
1. Open fuel filler flap and remove filler cap.
2. Disconnect battery earth lead.
3. Remove RH rear wheel arch liner.
See
CHASSIS AND BODY, Repair.
4. Remove nut securing filler neck bracket to stud.
5. Disconnect vent line quickfit connectors at
fuel/vapour separator and under body
connection.
6. Disconnect pressure sensor breather pipe
connection.
7. Remove shear cap from clip securing neck
assembly to tank.
8. Slacken clip securing neck assembly to tank.
9. Release filler neck bracket from body stud. Push
filler neck down then forwards to release from
aperture grommet.
10. Remove filler neck assembly.
