Range Rover P38
LAND ROVER V8
23
REPAIR
Refit
12. Fit ignition coil to bracket. Secure with screws.
13. Connect wires to terminals. Secure with nuts.
14. Fit terminal cover.
15. Position ignition coil bracket on inlet manifold
studs.
16. Secure fuel rail and ignition coil bracket with
nuts. Tighten to
8 Nm (6 lbf.ft)
17. Connect multiplug.
18. Connect H.T. leads to respective coil towers.
19. Reconnect battery negative lead.
IGNITION COILS - from 99MY
Service repair no - 18.20.45
Remove
1. Remove upper inlet manifold gasket.
See
MANIFOLD AND EXHAUST SYSTEM, Repair.
2. Remove 2 lower coil fixing bolts.
3. Disconnect multiplugs from coils.
4. Release HT leads from rocker covers and
disconnect HT leads from plugs.
5. Carefully manoeuvre coil assembly from
between engine and bulkhead.
