SuspensionSuspension · page 6 of 7
Diagram showing the rear suspension damper assembly with a callout to the welded nut at the bottom mount.

A Welded nut

  1. Lower the rear suspension and set the damper with the welded nut pointing to the front of the car.
Diagram showing the damper mounting nuts and bolts securing the damper to the chassis, with a torque callout.

A Damper mounting nuts

  1. Loosely install the damper mounting nuts.
  2. Loosely install the damper mounting bolts.
  3. Raise the rear suspension with a floor jack until the weight of the car is on the damper.

WARNING: The floor jack must be securely positioned or personal injury may result.

  1. Tighten the damper mounting bolt and nuts.
Diagram showing the lower part of the rear suspension, focusing on the damper mounting bolt connection.

A Damper mounting bolt

  1. Install the rear seat, see BODY.
  2. Install the rear wheel.
