Restraint systemsSystem components

SYSTEM COMPONENTS

System components
  1. Rotary coupler
  2. SRS warning light
  3. Driver’s airbag module
  4. Diagnostic socket
  5. SRS diagnostic control unit
  6. SRS harness
  7. Passenger’s airbag module
  8. Front seat belt pre-tensioner - 4/5 Door
  9. Front seat belt pre-tensioner - Coupe
  10. Front seat belt pre-tensioner to SRS harness connector
