Transmission Cover Installation (Manual Transmission - F17-5)

Make

Vauxhall

Model

Astra J

Section

Manual Transmission - F17-5 › Repair Instructions › Transmission Cover Installation

Transmission/TransaxleTransmission Cover Installation

Transmission Cover Installation Callout Component Name 1 Transmission Cover Gasket Procedure Clean the sealing surfaces and install a New gasket. 2 Transmission Cover Procedure Install a New transmission cover. 3 Transmission Cover Bolt M8 (Qty: 5) Caution: Refer to Fastener Caution . Tighten 20 N·m (15 lb ft) 4 Transmission Cover Bolt M6 (Qty: 4) Tighten 8 N·m (71 lb in)
