ABS - Location of components
- Make
- Fiat
- Model
- Stilo Factory Service Manual
- Year
- 2001–2007
- Section
- Vehicle electronic systems › ABS - Location of components
Wiring diagrams and electrical functionsABS - Location of components
ABS - Location of components
Location of components
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| B1 | Engine compartment junction unit | 5505A |
| B2 | Junction unit under dashboard | 5505A |
| B99 | Maxifuse box on battery | 5530B |
| C12 | ABS front earth | |
| C15 | Facia earth, driver's side | |
| D6 | Front / rear coupling | |
| D97 | Short circuiting coupling | |
| E50 | Instrument panel | 5560B |
| H1 | Ignition switch | 5520A |
| I30 | Brake pedal switch | |
| K70 | Left. front wheel sensor for ABS | 3340A |
| K71 | Right. front wheel sensor for ABS | 3340A |
| K75 | .Left rear wheel sensor for ABS | 3340A |
| K75 | Left rear wheel sensor for ABS. | 3340A |
| K76 | .Right rear wheel sensor for ABS | 3340A |
| K76 | Right rear wheel sensor for ABS. | 3340A |
| M1 | Body computer | 5505A |
| M50 | ABS control unit | 3340A |
Location of components
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| B1 | Engine compartment junction unit | 5505A |
| B2 | Junction unit under dashboard | 5505A |
| B99 | Maxifuse box on battery | 5530B |
| C12 | ABS front earth | |
| C15 | Facia earth, driver's side | |
| D6 | Front / rear coupling | |
| D97 | Short circuiting coupling | |
| E50 | Instrument panel | 5560B |
| H1 | Ignition switch | 5520A |
| I30 | Brake pedal switch | |
| K70 | Left. front wheel sensor for ABS | 3340A |
| K71 | Right. front wheel sensor for ABS | 3340A |
| K75 | .Left rear wheel sensor for ABS | 3340A |
| K75 | Left rear wheel sensor for ABS. | 3340A |
| K76 | .Right rear wheel sensor for ABS | 3340A |
| K76 | Right rear wheel sensor for ABS. | 3340A |
| M1 | Body computer | 5505A |
| M50 | ABS control unit | 3340A |
