ELECTRIC STEERING - Wiring diagram
Wiring diagram
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| B1 | Engine compartment junction unit | 5505A |
| B2 | Junction unit under dashboard | 5505A |
| B99 | Maxifuse box on battery | 5530B |
| C14 | Electric steering front earth | |
| C15 | Facia earth, driver's side | |
| C20 | Passenger side dashboard earth | |
| D20 | /Rear dashboard coupling | |
| D20 | Dashboard/rear coupling | |
| E50 | Instrument panel | 5560B |
| H1 | Ignition switch | 5520A |
| H35 | Switches on tunnel | |
| H35 | Switches on tunnel | 3350A |
| M1 | Body computer | 5505A |
| M86 | Electric steering control unit | 4110D |
