AIRBAG - Location of components

Location of components

COMPONENTS

Component code	Name	Assembly reference
B2	Junction unit under dashboard	5505A
B99	Maxifuse box on battery	5530B
C15	Facia earth, driver's side
C50	Air Bag earth
D1	Front / dashboard coupling
D1	Front/dashboard coupling
D6	Front / rear coupling
D6	Front/rear coupling
D20	/Rear dashboard coupling
D20	Dashboard/rear coupling
D47	Clock spring coupling	5580C
E50	Instrument panel	5560B
H1	Ignition switch	5520A
H75	Passenger's Air Bag disablement switch	5580C
H76	Rear Air Bags disabling switch
I45	Driver's seat belt warning light switch
I46	Passenger seat belt warning light switch
I46	Passenger seat belts warning light switch
K39	Air-Bag front sensor
K39	Air-bag front sensor
K65	Passenger Air Bag disabling sensor
K66	Sensor for driver's, Side Bag
K67	Passenger, Side Bag sensor
K67	Sensor for passenger, Side Bag
M1	Body computer	5505A
M60	Air Bag Control Unit
M60	Air bag control unit
Q9	Driver's Air Bag	5580C
Q11	Air Bag in dashboard (passenger side)	5580C
Q20	Driver's seat belt pre-tensioner	7065A
Q21	Front passenger seat belt pre-tensioner	7065A
Q21	Front passenger seat belt pretensioner	7065A
Q22	Left rear seat belt pretensioner
Q23	Right rear seat belt pretensioner
Q30	Driver's Side>Bag
Q30	Driver's Side Bag
Q31	Passenger Side Bag
Q40	Driver's Head Bag	5580C
Q41	Passenger Head Bag	5580C
Q42	Right rear Side Bag
Q43	Left rear Side Bag
