ROBOTIZED GEARBOX - Wiring diagram

Make

Fiat

Model

Stilo Factory Service Manual

Year

2001–2007

Section

Vehicle electronic systems › ROBOTIZED GEARBOX - Wiring diagram

Wiring diagrams and electrical functionsROBOTIZED GEARBOX - Wiring diagram

ROBOTIZED GEARBOX - Wiring diagram

2.4 20v · Smart gearbox

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit	5505A
B2	Junction unit under dashboard	5505A
B99	Maxifuse box on battery	5530B
C10	Front left earth
C11	Right front earth
C15	Facia earth, driver's side
C20	Passenger side dashboard earth
D1	Front / dashboard coupling
D1	Front/dashboard coupling
D4	Front/engine connection
D4	Front/engine coupling
D6	Front / rear coupling
D6	Front/rear coupling
D47	Clock spring coupling	5580C
D79	"Selespeed gearbox sensors coupling"
D79	'Selespeed gearbox sensors coupling'
D97	Short circuiting coupling
E47	Selespeed gearbox buzzer
E50	Instrument panel	5560B
H1	Ignition switch	5520A
H35	Switches on tunnel
H35	Switches on tunnel	3350A
H37	Gear controls	2127A
I30	Brake pedal switch
J87	"Selespeed gearbox relay"
J87	'Selespeed gearbox relay'
K68	Speed selection potentiometer	2127E
K69	Gear shift potentiometer	2127E
K78	Transmission output speed sensor	2127E
K96	Pressure sensor on transmission	2127E
K99	Sensor on clutch
L51	Solenoid 1 (gear engagement)
L52	Solenoid 2 (gear engagement)
L53	Solenoid 3 (gear engagement)
L56	Clutch control solenoid
M1	Body computer	5505A
M10	Engine management ECU	1056B
M10	Engine management control unit	1056B
M54	"Selespeed transmission control unit"	2127E
M54	'Selespeed transmission control unit'	2127E
N47	"Selespeed gearbox electric pump"	2127C
N47	'Selespeed gearbox electric pump'	2127C
