TD5 Defender
CHASSIS AND BODY
13
REPAIR
SEAT BELT - CENTRE - REAR
Service repair no - 76.73.20
Remove
1. Remove seat belt bolt caps and remove bolts.
2. Remove seat belt and stalk.
Refit
3. Position seat belt and stalk.
4. Fit and tighten bolts to 32 Nm (24 lbf.ft), and fit
bolt caps.
SEAT BELT - REAR - SIDE
Service repair no - 76.73.23
Remove
1. Remove cap from seat belt guide bolt.
2. Remove seat belt upper and lower securing
bolts.
3. Remove seat belt guide from ’D’ post finisher.
4. Remove 2 studs securing finisher to ’D’ post.
