TD5 Defender
CHASSIS AND BODY
29
REPAIR
25. Position console and connect Lucar and
multiplug to cigar lighter.
26. Connect multiplugs to remaining switches.
27. Fit console and secure with screws.
28. Fit crash pad and secure with screws.
29. Fit demister vents and secure with screws.
30. Fit grab handle, secure with screws and fit Land
Rover decal.
31. Fit heater control to fascia and secure with
screws.
32. Position instrument pack and connect multiplugs.
33. Fit instrument pack to fascia and secure with
screws.
34. Fit radio. See ELECTRICAL, Repair.
35. Connect battery earth lead. See ELECTRICAL,
Repair.
GLASS - REAR DOOR - FROM 02MY
Service repair no - 76.31.02
Remove
1. Remove rear door mounting panel. See this
Section.
2. Loosen 2 nuts and remove door check strap
torsion bar and plate.
3. Remove check strap.
4. Remove inner and outer waist seal.
5. Remove screw from each glass channel.
6. Lower glass to bottom of door, lift over lower
edge and withdraw from door.
