TD5 Defender
76
CHASSIS AND BODY
14
REPAIR
5. Release finisher from body upper rail and ’D’
post.
6. Pull seat belt through ’D’post finisher.
7. Remove bolt securing seat belt to ’D’ post and
remove belt assembly.
Refit
8. Position seat belt assembly to ’D’ post and
tighten bolt to 32 Nm (24 lbf.ft).
9. Extend seat belt and position through ’D’ post
finisher.
10. Fit and tighten seat belt upper and lower
securing bolts to 32 Nm (24 lbf.ft).
11. Secure ’D’post finisher to body upper rail.
12. Fit belt guide to ’D’ post finisher and fit finisher
retaining studs.
13. Fit cap to seat belt bolt.
SEAT - REAR
Service repair no - 78.10.48.99
Remove
1. Remove bolts securing rear seat to hinges and
collect spacer.
2. Remove rear seat.
Refit
3. Position rear seat and align to hinges.
4. Fit spacer and tighten bolts.
