TD5 Defender
86
ELECTRICAL
6
REPAIR
LAMP - TAIL
Service repair no - 86.40.70
Remove
1. Remove 2 screws securing tail lamp to body.
2. Disconnect multiplug and remove lamp.
Refit
3. Position tail lamp and connect multiplug.
4. Fit and tighten lamp securing screws.
RADIO
Service repair no - 86.50.03
Remove
1. Using tool SMD 4091 release radio from cage.
2. Disconnect coaxial cable from radio.
3. Disconnect 2 multiplugs from radio.
4. Remove radio from fascia.
Refit
5. Position radio to fascia and connect multiplugs.
6. Connect coaxial cable to radio.
7. Secure radio in cage.
