TD5 Defender
ELECTRICAL
19
REPAIR
RELAY - STARTER - FROM 02MY
Service repair no - 86.60.10
Remove
1. Remove 2 screws securing fuse cover and
remove cover.
2. Identify and remove relay.
Refit
3. Fit relay.
4. Fit fuse cover and secure with screws.
SWITCH - HEADLAMP LEVELLING - FROM 02MY
Service repair no - 86.65.16
Remove
1. Disconnect battery negative lead. See this
Section.
2. Remove fascia console. See CHASSIS AND
BODY, Repair.
3. Remove operating knob from light switch.
4. Remove nut securing light switch and remove
switch from console.
Refit
5. Fit light switch and secure with nut.
6. Fit operating knob to switch.
7. Fit fascia console. See CHASSIS AND BODY,
Repair.
8. Connect battery negative lead. See this
Section.
