L322 Range Rover Service Procedures
TORQUE WRENCH SETTINGS
06-14
Automatic Gearbox - V8
TORQUE DESCRIPTION
METRIC
IMPERIAL
Fluid drain plug
25 Nm
18 lbf.ft
Fluid filler/level plug
35 Nm
26 lbf.ft
Selector cable trunnion nut
15 Nm
11 lbf.ft
Gearshift selector to carrier nuts
25 Nm
18 lbf.ft
Selector cable to selector lever nut
15 Nm
11 lbf.ft
Starter inhibitor switch bolts
10 Nm
7 lbf.ft
Starter inhibitor switch harness bracket bolt
10 Nm
7 lbf.ft
Starter inhibitor switch guard bolts
10 Nm
7 lbf.ft
Selector lever to inhibitor switch nut
10 Nm
7 lbf.ft
Selector shaft nut
10 Nm
7 lbf.ft
Shift solenoid retaining bracket Torx bolts
10 Nm
7 lbf.ft
Valve block Torx bolts
10 Nm
7 lbf.ft
Speed sensor to valve block clamp Torx bolt
10 Nm
7 lbf.ft
Multiplug bracket bolt
10 Nm
7 lbf.ft
Gearbox to engine Torx bolts
45 Nm
33 lbf.ft
Fluid cooler banjo bolt
37 Nm
27 lbf.ft
Fluid cooler pipe union
37 Nm
27 lbf.ft
Fluid cooler saddle clamp bolt
6 Nm
4.4 lbf.ft
Drive plate to torque converter bolts
45 Nm
33 lbf.ft
Selector cable support bracket bolts
10 Nm
7 lbf.ft
Cross member bolts
68 Nm
50 lbf.ft
Mounting to cross member bolt
100 Nm
74 lbf.ft
Top bell housing Torx bolts
25 Nm
18 lbf.ft
Output flange housing to gearbox Torx bolts
10 Nm
7 lbf.ft
Sump Torx bolts
10 Nm
7 lbf.ft
