L322 Range Rover Service Procedures
TORQUE WRENCH SETTINGS
06-16
Steering
+ New nuts/bolts must be fitted
TORQUE DESCRIPTION
METRIC
IMPERIAL
Track rod end locknut
55 Nm
40 lbf.ft
Upper ball joint to hub nut
165 Nm
121 lbf.ft
Tie rod to sub frame nut
165 Nm
121 lbf.ft
Damper upper mounting nuts
56 Nm
40 lbf.ft
PAS pump high pressure pipe union
25 Nm
18 lbf.ft
PAS rack bolts/nuts +:
l
Stage 1
l
Stage 2
100 Nm
Further 90
°
74 lbf.ft
Further 90
°
PAS hose banjo bolts:
l
M14
l
M16
36 Nm
40 Nm
26 lbf.ft
30 lbf.ft
Column to PAS rack clamp screw
24 Nm
18 lbf.ft
Track rod ends to steering arm nuts +
80 Nm
59 lbf.ft
Road wheel nuts
140 Nm
103 lbf.ft
Track rod end ball joint nut +
80 Nm
59 lbf.ft
Lower steering column Torx clamp bolt
24 Nm
18 lbf.ft
PAS pump hose union nut
25 Nm
18 lbf.ft
PAS hose to mounting nut
10 Nm
7 lbf.ft
PAS pump brackets Torx bolts
25 Nm
18 lbf.ft
PAS pump to mounting - Td6:
l
M6 bolts
l
M8 bolts
10 Nm
25 Nm
7 lbf.ft
18 lbf.ft
PAS pump to mounting - V8:
l
Allen bolts
l
Nut
10 Nm
25 Nm
7 lbf.ft
18 lbf.ft
PAS pump pulley bolts
25 Nm
18 lbf.ft
PAS pump brackets Torx bolts
25 Nm
18 lbf.ft
PAS pump high pressure pipe union to
25 Nm
18 lbf.ft
Ancillary drive belt tensioner clamp bolts
30 Nm
22 lbf.ft
Steering wheel retaining bolt
63 Nm
46 lbf.ft
