L322 Range Rover Service Procedures
TORQUE WRENCH SETTINGS
06-10
Cooling System - Td6
Cooling System - V8
TORQUE DESCRIPTION
METRIC
IMPERIAL
Cylinder block drain plug
25 Nm
18 lbf.ft
Viscous fan coupling unit bolts
10 Nm
7 lbf.ft
Viscous fan coupling nut
45 Nm
33 lbf.ft
Thermostat housing bolts
8 Nm
6 lbf.ft
Coolant rail bolts
10 Nm
7 lbf.ft
EGR pipe heat shield Torx bolts
25 Nm
18 lbf.ft
Coolant rail to thermostat housing bolts
8 Nm
6 lbf.ft
Coolant pump bolts
10 Nm
7 lbf.ft
TORQUE DESCRIPTION
METRIC
IMPERIAL
Cylinder block drain plug
25 Nm
18 lbf.ft
Viscous fan coupling to unit bolts
10 Nm
7 lbf.ft
Viscous fan coupling nut
45 Nm
33 lbf.ft
Coolant manifold to cylinder heads bolts
10 Nm
7 lbf.ft
Multiplug to bell housing bolt
25 Nm
18 lbf.ft
Engine harness to coolant manifold bolt
10 Nm
7 lbf.ft
Coolant gallery sealing plate to cylinder block bolts
10 Nm
7 lbf.ft
Thermostat housing bolts
10 Nm
7 lbf.ft
Coolant pump bolts
10 Nm
7 lbf.ft
Coolant pump pulley bolts
10 Nm
7 lbf.ft
Secondary air injection pipe bolts
10 Nm
7 lbf.ft
