Range Rover V8 Manifold and Exhaust System Torque Wrench Settings
TORQUE WRENCH SETTINGS
06-11
Manifold and Exhaust System - Td6
+ New nuts and bolts must be fitted
* Not intermediate pipe mounting bracket
Manifold and Exhaust System - V8
+ New nuts must be fitted
TORQUE DESCRIPTION
METRIC
IMPERIAL
Exhaust mounting brackets to body nuts *
25 Nm
18 lbf.ft
Exhaust flange to front pipe nuts +
45 Nm
33 lbf.ft
Front pipe to turbocharger nuts
42 Nm
31 lbf.ft
Inlet manifold:
l
Bolts
l
Nuts
10 Nm
15 Nm
7 lbf.ft
11 lbf.ft
Intermediate pipe to tail pipe sleeve clamp nuts
48 Nm
35 lbf.ft
Intermediate pipe to front pipe nuts
25 Nm
18 lbf.ft
Intermediate pipe mounting bracket to body nut
68 Nm
50 lbf.ft
Vacuum pipe support bracket bolt
6 Nm
4.4 lbf.ft
Dipstick tube bracket bolt
6 Nm
4.4 lbf.ft
Exhaust manifold nuts
24 Nm
18 lbf.ft
TORQUE DESCRIPTION
METRIC
IMPERIAL
Exhaust mounting brackets to body nuts
25 Nm
18 lbf.ft
Exhaust flange to front pipe nuts +
45 Nm
33 lbf.ft
Intermediate pipe to front pipe sleeve clamp nuts
48 Nm
35 lbf.ft
Intermediate pipe to tail pipe sleeve clamp nuts
48 Nm
35 lbf.ft
Rear cover to inlet manifold Torx screws
10 Nm
7 lbf.ft
Brackets to inlet manifold bolts
10 Nm
7 lbf.ft
Fit front cover to inlet manifold Torx screws
10 Nm
7 lbf.ft
Inlet manifold nuts
15 Nm
11 lbf.ft
Exhaust manifold nuts
23 Nm
17 lbf.ft
