L322 Range Rover Wiper and Washer Torque Wrench Settings
TORQUE WRENCH SETTINGS
06-22
Heating and Ventilation
Air Conditioning
Wipers and Washers
TORQUE DESCRIPTION
METRIC
IMPERIAL
Plenum assembly nuts
10 Nm
7 lbf.ft
Positive cable to stud nut
20 Nm
15 lbf.ft
Heater pipe securing bolts
10 Nm
7 lbf.ft
Fuel burning heater mounting bracket bolts
10 Nm
7 lbf.ft
Fuse box bolts
6 Nm
4.4 lbf.ft
TORQUE DESCRIPTION
METRIC
IMPERIAL
Compressor drive belt tensioner bolts
25 Nm
18 lbf.ft
A/C pipes to compressor bolts
22 Nm
16 lbf.ft
A/C compressor mounting bolts
25 Nm
18 lbf.ft
A/C pipes to condenser
10 Nm
7 lbf.ft
TXV to A/C pipes clamp bolts
6 Nm
4.4 lbf.ft
A/C pipes to bulkhead bolts
6 Nm
4.4 lbf.ft
TORQUE DESCRIPTION
METRIC
IMPERIAL
Washer reservoir to body bolts
3 Nm
2.2 lbf.ft
Front wiper arm to spindle nut
34 Nm
25 lbf.ft
Wiper motor to bracket bolts
10 Nm
7 lbf.ft
Wiper linkage to motor nut
25 Nm
7 lbf.ft
Tailgate wiper arm to spindle nut
13 Nm
10 lbf.ft
