L322 Range Rover Service Procedures
TORQUE WRENCH SETTINGS
06-21
Body
+ New bolts must be fitted
TORQUE DESCRIPTION
METRIC
IMPERIAL
Lower tailgate striker bolts
25 Nm
18 lbf.ft
Front glass Torx bolts
10 Nm
7 lbf.ft
Front door glass regulator upper clamp bolts
10 Nm
7 lbf.ft
Front door glass regulator lower bolts +
10 Nm
7 lbf.ft
Rear door glass regulator upper bolts
10 Nm
7 lbf.ft
Rear door glass regulator lower bolts +
10 Nm
7 lbf.ft
Door pocket finisher nuts
3 Nm
2.2 lbf.ft
Door latch Torx screws
10 Nm
7 lbf.ft
Spoiler to tailgate bolts
10 Nm
7 lbf.ft
Bumper armature:
l
Bolts
l
Nuts
10 Nm
45 Nm
7 lbf.ft
33 lbf.ft
Door mirror assembly to door Torx screws
10 Nm
7 lbf.ft
Door mirror motor to cheater, Torx screws
14 Nm
10 lbf.ft
'A' post trim screw
2 Nm
1.5 lbf.ft
Fascia to bulkhead nuts and bolts
25 Nm
18 lbf.ft
HEVAC to bulkhead nuts
10 Nm
7 lbf.ft
Steering column clamp Torx bolt
25 Nm
18 lbf.ft
Centre console support bracket bolts
10 Nm
7 lbf.ft
Handbrake mounting bracket to body bolts
25 Nm
18 lbf.ft
Automatic gearbox selector carrier nuts
25 Nm
18 lbf.ft
Centre fascia support bracket bolts
25 Nm
18 lbf.ft
Headlining to sunshine roof screws
2.5 Nm
1.9 lbf.ft
Seat securing nuts and bolts
45 Nm
33 lbf.ft
Seat belt to seat bolt
48 Nm
35 lbf.ft
Rear seat securing nuts and bolts
25 Nm
18 lbf.ft
Sun roof motor:
l
Torx screws
l
Allen screw
5 Nm
10 Nm
3.7 lbf.ft
7 lbf.ft
Tailgate latch bolts
10 Nm
7 lbf.ft
