TORQUE WRENCH SETTINGS
06-18
Rear Suspension
+ New nuts/bolts must be fitted
TORQUE DESCRIPTION
METRIC
IMPERIAL
Lower arm to hub bolt +
250 Nm
184 lbf.ft
Hub nut +
420 Nm
311 lbf.ft
Upper arm to hub bolt +
165 Nm
121 lbf.ft
Brake pipe to upper arm Allen screw
5 Nm
3.7 lbf.ft
Air pipe connection
3.5 Nm
2.6 lbf.ft
Damper to lower arm bolt +
110 Nm
81 lbf.ft
Damper spindle nut
27 Nm
20 lbf.ft
Damper upper mounting nuts +
56 Nm
40 lbf.ft
Anti-roll bar bush clamp bolts +
38 Nm
28 lbf.ft
Anti-roll bar link nuts +
100 Nm
74 lbf.ft
Tie rod ball joint nut +
165 Nm
121 lbf.ft
Height sensor link to lower arm nut
19 Nm
14 lbf.ft
Tie rod to sub-frame bolt +
165 Nm
121 lbf.ft
Anti-roll bar link nuts +
100 Nm
74 lbf.ft
Lower arm to sub-frame bolts +
165 Nm
121 lbf.ft
Upper arm to sub-frame bolts +
165 Nm
121 lbf.ft
Sub-frame to body bolts +
165 Nm
122 lbf.ft
Height sensor to mounting bracket Allen screws
5 Nm
3.7 lbf.ft
