L322 Range Rover Service Procedures
TORQUE WRENCH SETTINGS
06-8
Engine management system - V8
TORQUE DESCRIPTION
METRIC
IMPERIAL
Spark plugs
31 Nm
23 lbf.ft
Ignition coil nuts
4 Nm
3 lbf.ft
Earth lead to camshaft cover nut
4 Nm
3 lbf.ft
'E' box cover Allen screws
2 Nm
1.5 lbf.ft
Engine coolant temperature sensor (ECT)
15 Nm
11 lbf.ft
Crankshaft position sensor (CKP) Allen screw
10 Nm
7 lbf.ft
Camshaft position sensor (CMP) bolt
10 Nm
7 lbf.ft
Knock sensor (KS) bolts
20 Nm
15 lbf.ft
Accelerator pedal to bracket Allen screw
10 Nm
7 lbf.ft
Inlet manifold bracket bolts
10 Nm
7 lbf.ft
