L322 Range Rover Service Procedures
TORQUE WRENCH SETTINGS
06-6
Emission control - Td6
Emission control - V8
+ Apply anti-seize compound to threads
TORQUE DESCRIPTION
METRIC
IMPERIAL
Depression valve Allen screws
8 Nm
6 lbf.ft
Injector harness screws
2 Nm
1.5 lbf.ft
EGR valve bolts
10 Nm
7 lbf.ft
EGR solenoid valve nuts
10 Nm
7 lbf.ft
EGR cooler Allen screws
25 Nm
18 lbf.ft
Intercooler hose assembly to EGR valve
Wait 10 minutes and re-torque intercooler hose assembly to EGR valve
6 NM
6 Nm
4.4 lbf.ft
4.4 lbf.ft
TORQUE DESCRIPTION
METRIC
IMPERIAL
SAI pump bolts:
l
Upper
l
Lower
22 Nm
5 Nm
16 lbf.ft
4 lbf.ft
SAI control valve to manifold bolts
10 Nm
7 lbf.ft
HO2S +
50 Nm
37 lbf.ft
