L322 Range Rover Service Procedures
TORQUE WRENCH SETTINGS
06-5
+ New bolts must be fitted
* Correct tightening sequence must be followed
Connecting rod - big-end bearing cap bolts * +:
l
Stage 1
l
Stage 2
l
Stage 3
5 Nm
20 Nm
Further 80
°
4 lbf.ft
15 lbf.ft
Further 70
°
Crankshaft - main bearing cap bolts * +:
l
Stage 1
l
Stage 2
20 Nm
Further 100
°
15 lbf.ft
Further 100
°
Crankshaft - main bearing cap adjustable spacers
10 Nm
7 lbf.ft
Crankshaft - main bearing cap adjustable spacer bolts
l
Stage 1
l
Stage 2
20 Nm
Further 45
°
15 lbf.ft
Further 45
°
TORQUE DESCRIPTION
METRIC
IMPERIAL
