TORQUE WRENCH SETTINGS
06-9
Fuel Delivery System - Td6
Fuel Delivery System - V8
TORQUE DESCRIPTION
METRIC
IMPERIAL
Fuel filter to mounting bracket bolt
6 Nm
4.4 lbf.ft
Fuel pressure sensor to filter retaining clamp Torx bolt
6 Nm
4.4 lbf.ft
Fuel pump locking ring
35 Nm
26 lbf.ft
Fuel tank RH access panel nuts
10 Nm
7 lbf.ft
Fuel tank to body bolts
45 Nm
33 lbf.ft
Fuel tank shield nuts and bolts
25 Nm
18 lbf.ft
TORQUE DESCRIPTION
METRIC
IMPERIAL
Fuel pump locking ring
35 Nm
26 lbf.ft
Fuel tank RH access panel nuts
10 Nm
7 lbf.ft
Fuel tank to body bolts
45 Nm
33 lbf.ft
Fuel tank shield nuts and bolts
25 Nm
18 lbf.ft
