Range Rover P38
LAND ROVER V8
33
REPAIR
ENGINE MOUNTINGS - up to 99MY
Service repair no - 12.45.01 - LH
Service repair no - 12.45.02 - RH
Remove
1. Disconnect battery negative lead.
2. With assistance, release bonnet struts from body
locations. Retain bonnet in vertical position using
stay clips.
WARNING: Only open the bonnet to the
vertical position with the vehicle on a
horizontal surface in the workshop. This
position is not intended to be used outdoors
where the bonnet could be affected by winds.
3. Right Hand Mounting Only: Fit lifting eye to
alternator bracket.
4. RHD - Right Hand Mounting Only: Remove
steering column intermediate shaft.
See
STEERING, Repair.
5. Left Hand Mounting Only: To prevent strain on
cruise control cable, disconnect from abutment
and actuator diaphragm.
6. Raise vehicle on four post lift.
7. Remove 4 nuts securing mounting to chassis
and engine. Discard nuts.
