Range Rover P38
LAND ROVER V8
25
REPAIR
FLYWHEEL
Service repair no - 12.53.07
Remove
1. Remove clutch assembly.
See CLUTCH,
Repair.
2. Rotate flywheel until location dowel is opposite
starter motor.
3. Remove 6 flywheel securing bolts. Remove
flywheel.
4. Inspect flywheel clutch face for cracks, scores or
overheating.
5. Inspect ring gear for worn, chipped or broken
teeth.
Refit
6. Ensure mating surfaces, dowel and dowel
locations in both flywheel and crankshaft are
clean.
7. Offer flywheel up to crankshaft. Locate on dowel.
8. Refit flywheel bolts. Tighten to
80 Nm (59 lbf.ft)
9. Refit clutch assembly.
See CLUTCH, Repair.
