Range Rover P38
LAND ROVER V8
35
REPAIR
ENGINE MOUNTINGS - from 99MY
Service repair no - 12.45.11 - LH
Service repair no - 12.45.12 - RH
Remove
1. With assistance, release bonnet struts and retain
bonnet in vertical position with stay clips.
2. Release fixings and remove battery cover.
3. Disconnect battery earth lead.
4. Remove bolt securing screen washer filler tube.
5. Release 2 clips and remove cooling fan cowl.
6. Remove ties securing harness to support
bracket at rear of engine and move harness
clear of bracket.
7. Remove bolt securing harness support bracket
and remove bracket.
8. Right hand engine mounting: Fit suitable lifting
eye to alternator fixing bolt.
9. RHD - Right hand engine mounting: Remove
steering column intermediate shaft.
See
STEERING, Repair.
10. Raise vehicle on 4 post ramp.
11. Remove and discard 4 nuts securing engine
mounting.
12. Connect hoist to lifting eye and raise relevant
side of engine.
13. Remove engine mounting.
