ROCKER COVER GASKET - up to 99MY
Service repair no - 12.29.39 - Gaskets - Pair
Service repair no - 12.29.40 - LH Cover Gasket
Service repair no - 12.29.41 - RH Cover Gasket
Remove
1. Disconnect battery negative lead.
2. Disconnect crankcase breather hose from cover.
NOTE: Instructions 3,4,5 & 6 apply to
RH
Cover Only.
3. Depressurise fuel system.
See FUEL SYSTEM,
Repair.
4. Remove fuel feed pipe from fuel rail.
5. Release fuel pressure regulator return pipe from
clip.
6. Release heater hose from clip on inlet manifold.
NOTE: Instructions 7,8 & 9 apply to
LH
Cover Only.
7. Release plenum chamber. Place aside for
access.
See FUEL SYSTEM, Repair.
8. Release purge hose from ram pipe housing.
Place hose aside.
