Range Rover P38
LAND ROVER V8
29
REPAIR
GASKET - FRONT COVER - from 99MY
Service repair no - 12.65.04
Remove
1. Remove oil pick-up strainer.
See this section.
2. Remove front cover oil seal.
See this section.
3. Drain cooling system.
See COOLING SYSTEM,
Repair.
4. Remove bolt securing auxiliary belt jockey pulley
and remove pulley.
5. Remove 3 bolts securing water pump pulley and
remove pulley.
6. Release clip and disconnect bottom hose from
radiator.
7. Release clip and disconnect top hose from
radiator.
8. Release clip and disconnect coolant hose from
water pump.
9. Release thermostat housing from radiator cowl
and move hoses clear of front cover.
