ENGINE
NEW RANGE ROVER
38
REPAIR
OIL FILTER
Service repair no - 12.60.04
Remove
1. Raise front of vehicle.
WARNING: Support on safety stands.
2. Remove engine acoustic cover (if applicable).
See CHASSIS AND BODY, Repair.
3. Position drain tray to catch spillage.
4. Remove oil filter cartridge.
Refit
5. Clean mating face of oil pump.
6. Lubricate oil filter seal with clean engine oil.
7. Fit oil filter and tighten until rubber seal contacts
machined face. Tighten a further half turn by
hand.
CAUTION: DO NOT overtighten oil filter.
8. Run engine to allow oil to fill filter.
9. Stop engine, check and top up oil level.
See
LUBRICANTS, FLUIDS AND CAPACITIES,
Information.
10. Fit engine acoustic cover (if applicable).
See
CHASSIS AND BODY, Repair.
11. Remove stand(s) and lower vehicle.
OIL COOLER
Service repair no - 12.60.68
Remove
1. Disconnect battery negative lead.
2. Raise the vehicle.
WARNING: Support on safety stands.
3. Remove front grille.
See CHASSIS AND BODY,
Repair.
4. Release 2 clips securing bonnet release cable to
bonnet platform.
5. Remove 4 bolts securing bonnet platform.
Remove platform.
6. Remove 4 bolts from condenser mounting
brackets. Collect 2 brackets.
