Range Rover Classic
Tdi
23
REPAIR
VACUUM PUMP
Service repair no - 70.50.19
Remove
NOTE: To ease pump removal set engine
to T.D.C. on No.1 cylinder.
1. Disconnect battery negative lead.
2. Detach servo hose from vacuum pump.
3. Remove six bolts securing vacuum pump.
4. Detach pump complete with harness bracket.
Note location of bracket for refitting.
Refit
5. Clean mating faces of pump and block.
6. Loosely assemble pump to block with a new
gasket and with harness bracket located under
head of bolt noted during removal.
7. Evenly tighten bolts, to depress pump plunger,
finally tightening to
25 Nm.
8. Connect vacuum hose and secure with clip.
9. Reconnect battery negative lead.
GENERATOR
Service repair no - 86.10.02
Remove
1. Disconnect battery negative lead.
2. Remove drive belt.
See Drive Belt Renew
3. Disconnect electrical leads from rear of
generator.
4. Remove securing bolt from bottom of generator.
5. Remove long through bolt from top fixing and
withdraw generator.
Refit
6. Reverse removal procedure.
