Range Rover Classic
12
ENGINE
16
REPAIR
8. Ensure housing seal is correctly seated in its
groove in new housing and seal assembly.
9. Fit new assembly, with former/guide in-situ, over
crankshaft flange, this action will eject
former/guide.
10. Secure assembly to cylinder block with five bolts
tightened to correct torque, removing slave studs
individually and inserting bolts.
11. Refit flywheel.
See Flywheel
12. Refit clutch.
See CLUTCH, Repair, Clutch
Assembly
13. Refit gearbox.
See MANUAL GEARBOX,
Repair, R380 Manual Gearbox
14. Reconnect battery negative lead.
CRANKSHAFT BEARING BUSH
Service repair no - 12.21.45
1. Disconnect battery negative lead.
2. Remove gearbox.
See MANUAL GEARBOX,
Repair, R380 Manual Gearbox
3. Remove clutch.
See CLUTCH, Repair, Clutch
Assembly
4. Remove flywheel.
See Flywheel
5. Remove bearing bush.
NOTE: The bearing bush can be removed
by using one of the following methods.
Method 1.
Obtain a short length of steel rod of a diameter having
a good slide fit in the bore of the bush. Pack the bore
with grease and insert the steel rod into the end of the
bore, give a sharp blow with a hammer and the
grease should drive out the bush. It is recommended
that the bush and rod be covered by a suitable cloth
or rag to prevent grease from splashing.
