Range Rover Classic
12
ENGINE
18
REPAIR
10. Apply sealant to flywheel housing mating face on
cylinder block (Fig. J5944).
11. Fit housing to cylinder block and secure with
bolts as removed. Tighten to
45 Nm.
12. Remove surplus sealant from block.
13. Refit starter motor.
14. Refit flywheel.
See Flywheel
15. Refit clutch.
See CLUTCH, Repair, Clutch
Assembly
16. Refit gearbox.
See MANUAL GEARBOX,
Repair, R380 Manual Gearbox
17. Reconnect battery negative lead.
OIL FILTER
Service repair no - 12.60.01
Remove
1. Place drain tray under filter.
2. Unscrew filter anti-clockwise, using a strap or
spanner.
Refit
3. Smear clean engine oil on seal of new filter.
4. Screw on filter until sealing ring touches
machined face, then tighten a further half turn by
hand only. Do not over tighten.
