Fiat Ducato Factory Service Manual (2002-2006)20 · Wiring diagrams and electrical functions
20 · Electrical

Dipped beams location components

Make
Fiat
Model
Ducato Factory Service Manual
Year
2002–2006
Section
Exterior lighting › Dipped beams location components
Wiring diagrams and electrical functionsDipped beams location components

DIPPED BEAMS LOCATION COMPONENTS

Location Components

DIPPED BEAMS LOCATION COMPONENTS
Component codeDescriptionReference to the assembly
B001JUNCTION UNIT
B099MAXI FUSE BOX ON BATTERY
C010LEFT FRONT EARTH
C015DASHBOARD EARTH, DRIVER'S SIDE
D001FRONT/DASHBOARD COUPLING
F010LEFT HEADLAMP
F011RIGHT HEADLAMP
H005STEERING COLUMN SWITCH UNIT
H090SWITCH CONTROL PANEL
