ELECTRICAL
19
DESCRIPTION AND OPERATION
For 02MY a new fascia console has been introduced to accommodate the additional switches for electric windows
etc.
The console comprises a plastic moulding secured to the fascia with five screws. The new console allows existing
switches to be repositioned and has provided the opportunity to commonise the switches with other Land Rover
models. The switches and components located in the console are as follows:
•
Cigar lighter (if fitted)
•
Headlamp levelling control
•
LH and RH heated front seat switches (if fitted)
•
LH and RH front window lift switches
•
Front fog lamp switch (if fitted)
•
Rear fog lamp switch
•
Rear wash/wipe switch
•
Rear wiper switch
•
Hazard warning lamp switch
•
Heated rear window switch
•
Heated front screen switch (if fitted)
A central cut-out in the console provides for the installation of the radio, where fitted, or a coin tray for markets
without a standard radio installation.
