Backboard - front seat - models with adjustable upper squab (page 2 of 2)

SEATS

REPAIRS 76-5-15

3. Remove 2 screws securing lower squab

finisher.

4. Release lower finisher from 6 retaining clips

and remove finisher.

5. Disconnect 2 tension straps securing upper

squab cover.

6. Release velcro strip securing squab cover.

7. Release beading from squab cover finisher.
8. Release finisher from 4 retaining clips and

remove backboard.

Refit

1. Position upper squab cover finisher and secure

retaining clips.

2. Secure squab cover beading to finisher.
3. Secure squab cover velcro strip.
4. Connect tension straps securing squab cover.
5. Position lower finisher and secure retaining

clips.

6. Fit screws securing lower finisher.
7. Fit backboard tension straps to under seat

retaining clips.

8. Fit seat assembly.

 +

 SEATS, REPAIRS, Front seat.
