L322 Range Rover Service Procedures
SEATS
REPAIRS 76-5-21
Switch - lumbar support
$% 78.60.15
Before disconnecting the battery, ensure all text and
cautions in the battery disconnection section are
observed.
GENERAL INFORMATION, Electrical
Remove
1. Raise seat cushion.
2. Make the SRS system safe.
Supplementary Restraint System (SRS)
Precautions.
WARNING: Always disconnect both battery
leads before beginning work on the SRS
system. Disconnect the negative lead first.
Never reverse connect the battery.
3. Remove screw securing valance.
4. Release 3 fixings securing outer valance and
carefully release valance from seat.
Models with electric seats have 4 fixings.
5. Disconnect multiplug from lumbar support
switch.
6. Release and remove lumbar support switch.
Refit
1. Fit lumbar support switch.
2. Connect multiplug to lumbar support switch.
3. Align fixings, carefully fit valance and secure
with screw.
4. Connect battery leads, earth lead last.
5. Reposition seat.
