TORQUE WRENCH SETTINGS

06-3

* Correct tightening sequence must be followed

+ New bolts must be fitted

++ New pins must be fitted

+++ New Allen screw must be fitted

Oil cooler to oil filter housing bolts

22 Nm

16 lbf.ft

Timing chain lubrication jet bolt

10 Nm

7 lbf.ft

Fuel pump sprocket retaining nut

65 Nm

48 lbf.ft

Fuel pump drive chain lower guide pin Allen screw +++

 24 Nm

18 lbf.ft

Timing chain tensioner bolts

10 Nm

7 lbf.ft

Timing cover bolts

15 Nm

11 lbf.ft

Ancillary belt tensioner arm nut

10 Nm

7 lbf.ft

Compressor mounting bracket bolts

25 Nm

18 lbf.ft

Alternator and jockey pulley bracket bolts

45 Nm

33 lbf.ft

Ancillary drive belt upper idler pulley Allen screw

25 Nm

18 lbf.ft

Connecting rod - big-end bearing cap bolts * +:

l

Stage 1

l

Stage 2

l

Stage 3

5 Nm
25 Nm
Further 70

°

4 lbf.ft
18 lbf.ft
Further 70

°

Crankshaft - main bearing cap bolts * +:

l

Stage 1

l

Stage 2

20 Nm
Further 70

°

15 lbf.ft
Further 70

°

TORQUE DESCRIPTION

METRIC

IMPERIAL
