Range Rover P38
SEATS
5
REPAIR
DRIVE CABLE - HEADREST - up to 99MY
Remove
1. Remove squab heating element.
See this
section.
2. Remove 2 clips securing drive cable to motor
and headrest saddle.
3. Remove cable.
Refit
4. Fit cable to motor and saddle. Secure with clips.
NOTE: Cable run is under the squab cover
retention wire upper anchor rod.
5. Fit squab heating element.
See this section.
DRIVE CABLE - HEADREST - from 99MY
Service repair no - 78.70.50
Remove
1. Remove squab cover and squab foam as an
assembly.
See this section.
2. Remove clip securing cable to headrest saddle.
3. Remove 2 Torx screws securing motor.
4. Release motor and remove drive cable retaining
clip.
5. Remove drive cable.
