Range Rover P38
SEATS
35
REPAIR
SEAT OUTSTATION - from 99MY
Service repair no - 78.70.01
NOTE: Seat outstation is used on
electrically operated seats with memory
function.
1. Remove front seat.
See this section.
2. Remove 2 screws securing seat outstation
mounting bracket to cushion frame.
3. Remove 2 nuts securing outstation to mounting
bracket.
4. Release outstation from mounting bracket and
disconnect 4 multiplugs.
5. Remove outstation.
Refit
6. Position outstation, connect multiplugs and
locate on mounting bracket. Fit and tighten nuts.
7. Align outstation mounting bracket to cushion
frame and fit screws.
8. Fit seat.
See this section.
MOTOR - TILT - FRONT SEAT - from 99MY
Service repair no - 78.70.29
Remove
1. Remove front seat.
See this section.
2. Disconnect and release multiplug from bracket.
3. Remove roll pin securing motor.
4. Remove spring clip securing operating rod to
lever.
5. Release and remove motor assembly.
